RECESSED
800 Series / LED
805 SUPER SHALLOW
NEW CONSTRUCTION
Premium, feature rich, super shallow, recessed LED single-lamp lighting solution.
Source: LED Static White and Warm Dimming
Lamp Modules: 0-35° Adjustable Accent/Wall Wash, Fixed Downlight, and Fixed Wall Wash
Aperture Size: 1-3/4″ and 2-3/4”
Delivered Lumens: 1093 / 1483 lm
Wattage: 14.5 / 20.5 W
Beamspreads: 10°, 15°, 25°, 40°, and Wall Wash
800 Series / LED
804S LOW PROFILE
NEW CONSTRUCTION
Premium, feature rich, low profile, recessed LED single-lamp lighting solution.
Source: LED Static White, Tunable White, and Warm Dimming
Lamp Modules: 0-45° Adjustable Accent / Wall Wash, Fixed Downlight, and Mirror Reflector
Aperture Size: 1-3/4” and 2-3/4″
Delivered Lumens: 1129 / 1472 lm
Wattage: 14.5 / 20 W
Beamspreads: 10°, 15°, 25°, 40°, and Wall Wash
800 Series / LED
804S LOW PROFILE MULTI-LAMP
NEW CONSTRUCTION
Premium, feature rich, low profile, recessed LED multi-lamp lighting solution.
Source: LED Static White and Warm Dimming
Lamp Module: 0-45° Adjustable Accent, 0-45° Adjustable Wall Wash, Fixed, and Mirror Reflector
Delivered Lumens: 1044 lm
Wattage: 14.5 W
Beamspreads: 10°, 15°, 25°, 40°, and Wall Wash
800 Series / LED
804D LOW PROFILE DEEP CEILING
NEW CONSTRUCTION
Premium, feature rich, low profile, recessed LED single-lamp lighting solution for deep sheetrock ceiling applications.
Source: LED Static White, Tunable White, and Warm Dimming
Lamp Modules: 0-45° Adjustable Accent / Wall Wash, Fixed Downlight, and Mirror Reflector
Aperture Size: 1-3/4″ and 2-3/4”
Delivered Lumens: 1129 / 1472 lm
Wattage: 14.5 / 20 W
Beamspreads: 10°, 15°, 25°, 40°, and Wall Wash
800 Series / LED
RETROFIT
MODELS 801 / 802 / 803
Retrofit LED light engines to upgrade existing 800 Series recessed incandescent or LED models to the latest in LED technology.
Source: LED Static White and Warm Dimming
Lamp Modules: 0-45° Adjustable Accent / Wall Wash and Mirror Reflector
Aperture Size: 1-3/4″ and 2-3/4”
Delivered Lumens: 1044 lm
Wattage: 14.5 W
Beamspreads: 10°, 15°, 25°, 40°, and Wall Wash
400 Series / LED
NEW CONSTRUCTION
Efficient and flexible recessed LED single-lamp lighting solution.
Source: LED Static White and Warm Dimming
Lamp Module: 0-35° Adjustable Accent and 0-35° Adjustable Wall Wash
Aperture Size: 2”
Delivered Lumens: 1082 lm
Wattage: 14.5 W
Beamspreads: 10°, 15°, 25°, 40°, and Wall Wash
400 Series / LED
REMODEL
Efficient and flexible recessed LED single-lamp lighting solution.
Source: LED Static White and Warm Dimming
Lamp Module: 0-35° Adjustable Accent and 0-35° Adjustable Wall Wash
Aperture Size: 2”
Delivered Lumens: 1082 lm
Wattage: 14.5 W
Beamspreads: 10°, 15°, 25°, 40°, and Wall Wash
200 Series / LED
200-HD
NEW CONSTRUCTION
Efficient and value-focused recessed LED single-lamp lighting solution for HOSPITALITY, DESIGN, and COMMERCIAL applications.
Source: LED Static White and Warm Dimming
Models: 200-HD-S and 200-HD-R 0-30° Adjustable for general, accent, and wall wash applications
Aperture Size: 1-7/8″, 2-1/4″, and 2-3/4″
Delivered Lumens: 1751 / 2130 lm
Wattage: 19.5 / 26 W
Beam Spreads: 15°, 25°, 40°, 60°, and Wall Wash
200 Series / LED
NEW CONSTRUCTION
Efficient and value-focused recessed LED single-lamp lighting solution.
Source: LED Static White and Warm Dimming
Models: 202 0-30° Adjustable and 203 Wall Wash
Aperture Size: 1-7/8″, 2-1/4″, and 2-3/4″
Delivered Lumens: 1230 lm
Wattage: 14 W
Beam Spreads: 15°, 25°, 40°, 60°, and Wall Wash
200 Series / LED
REMODEL
Efficient and value-focused recessed LED single-lamp lighting solution.
